Solar Thermal Training System

The Solar Thermal Training System is a compact, modular platform designed to replicate real-world flat plate solar water heating systems. Engineered for both educational and research applications, it facilitates hands-on experimentation with key thermal performance parameters such as efficiency, overall heat loss coefficient (UL), and heat removal factor (FR). The system's adaptability allows users to conduct experiments under varying conditions, including different wind speeds, fluid temperatures, flow rates, and irradiation levels, making it an invaluable tool for comprehensive thermal analysis.

Key Features

Dual Mode Operation
Supports both thermosyphonic and forced circulation modes, enabling comparative studies of natural and pumped fluid flow.
Artificial Irradiation Source
Equipped with a 3200 W halogen lamp fixture with adjustable intensity, allowing for controlled indoor experiments independent of weather conditions.
Wind Simulation Capability
Features an artificial wind source with adjustable speeds ranging from 0 to 5 m/s to study convective heat losses.
Comprehensive Measurement Suite
Includes sensors and meters for real-time monitoring of temperature, pressure, flow rate, solar radiation, and wind speed, enhancing data accuracy and analysis.
Modular and Scalable Design
The system's modularity allows for easy transportation and setup, facilitating experiments both indoors and outdoors.
Adjustable Collector Orientation
Provides the ability to modify the tilt and incident angles of the collector, enabling studies on the impact of orientation on system performance.
Data Logging and Analysis
Integrated data logging capabilities allow for the recording and analysis of experimental data over time.
Auxiliary Tanks for Continuous Operation
Includes two auxiliary tanks to ensure uninterrupted experimentation and facilitate studies on thermal storage.
Manual Pump Control
A manually controlled hot water pump enables step-by-step observation of fluid dynamics and user-directed experimentation, reinforcing foundational understanding of solar thermal fluid circulation.

Learning Module

Solar Thermal System Efficiency and Performance Testing

Assess how changing environmental factors like solar irradiance, ambient temperature, and wind speed impact thermal efficiency.
Optimize collector orientation and tilt angle to maximize solar energy absorption.
Conduct real-time performance analysis using integrated sensors and data logging tools.

Heat Transfer, Loss Analysis, and Collector Performance

Determine the Heat Removal Factor (FR) and Overall Heat Loss Coefficient (UL) to assess collector performance.
Study convective heat losses using a built-in adjustable wind simulation system (0–5 m/s).
Analyze the effect of fluid temperature, flow rate, and irradiation levels on thermal energy collection and retention.

Fluid Circulation Methods: Thermosyphon vs. Forced Circulation

Conduct controlled experiments to understand the physics of each fluid circulation method.
Use manual pump control for detailed observation of hot water flow dynamics and system response.
Explore real-world scenarios and operating conditions to strengthen foundational knowledge of solar water heating systems.
